Key Features:
4000 dpi true optical resolution
14-bit A/D converter
New Scanner Nikkor ED glass lens
Proprietary LED illumination technology
Fast 38-second scanning
High-quality CCD sensor
Direct film loading
New advanced image processing algorithm for color negative film
Quick AF and Quick Preview
All New Scan Image Enhancer
High-speed USB 2.0 interface
Digital ICE-4 Advanced" (Digital ICE Quad Advanced)
Technical Specifications:
Media: Negative and positives, in color and monochrome
35mm slides: Slides with mounts 1.0-3.2mm thick, 49-50.8mm wide
35mm film strips: 2-6 frames; strips of 1-6 frames can be scanned with the included Strip Film Holder FH-3
APS (IX240) film: Cartridges of 15, 25, and 40 frames can be scanned with the optional IX240 Film Adapter IA-20(s)
Slide Glass for microscopes: Prepared slides (26x76mm, 0.8-1.5mm thick) can be scanned with optional Medical Slide Holder FH-G1
Aperture/Scan range (pixels):
MA-21: 25.1 x 36.8mm/3,946 x 5,782 pixels/Same as slide mount
SA-21: 25.1 x 38.0mm/3,946 x 5,959 pixels/23.4 x 36.0mm
IA-20(s): 18.6 x 28.4mm/2,915 x 4,453 pixels/16.1 x 27.4mm
Scanning system: Fixed film, movable plane single-pass optical scanning system
Light Source: R, G, B, and Infrared (IR) LEDs
Image sensor: 3,964-pixel linear CCD image sensor
Color separation: Performed by RGB LEDs
Optical resolution: Up to 4,000 pixels per inch
A/D conversion: 16 bits per color
Density range: 4.2
Output: Full color or greyscale at 8 or 16 bits per channel
Focus: Auto and manual; autofocusing point selectable
Interface: USB 2.0
Power requirements: AC 100-240V, 50/60Hz
Operating environment: Temperature 50-95°F (10-35°C)Relative humidity 20-60%
Dimensions: 3.8 x 6.8 x 12.4 in. (96 x 172 x 315mm) (W x H x D)
Weight: 6.6 lbs (3kg)
Orientation: Horizontal or vertical
Scanning time: (time to complete preview or scan when no options selected): Preview: 14 seconds Scan*: 38 seconds (time to complete preview or scan when no options are selected)* includes time required to display the scanned image
Nikon Scan 4 Requirements:
Windows:
CPU: Pentium® 300 MHz or faster
OS: Windows®98SE, Windows®Me, Windows®200 Professional, Windows®XP Home Edition, Windows®XP Professional pre-installed model
RAM*: 128MB or more (512MB or more recommended)
Hard disk**: 40MB required for installation (200MB recommended), with an additional 200MB of free disk space available while Nikon Scan is running)
Display: 800x600 with 16-bit colors (full color recommended)
Interface: USB***: Built-in USB 1.1 ports, USB 2.0
Others: CD-ROM drive required for installation
Macintosh:
CPU: Power PC G3 or later (G4 or later recommended)
OS: Mac®OS 9 (9.1 or later), Mac®OS X (10.1.5 or later)
RAM*: Mac®OS 9: 64MB or more (256MB or more recommended) Mac®OS X: 128MB or more (512MB or more recommended)
Hard disk**: 70MB required for installation (200MB recommended), with an additional 200MB (Mac®OS 9) or 550MB (Mac®OS X) of free disk space while Nikon Scan is running
Display: 800x600 with 16-bit colors (full color recommended)
Interface: USB***: Built-in USB 1.1 ports, USB 2.0
Others: CD-ROM drive required for installation
Nikon Authorized Dealer
Nikon Limted Warranty included
Click here to download the Brochure
in PDF format for Nikon Coolscan V ED Film Scanner
